We would normally track if a DOM element is visible in the viewport or not to understand user behavior or to operate on the element based on visibility (animation, AJAX calls, etc).

The Old Way

We would normally apply a function like this to detect if an element is visible:

const isInView = (elm, {top, height} = elm.getBoundingClientRect()) =>
  top <= innerHeight && top + height >= 0;

Later we would mostly add it on scroll events to trigger the checks as the user scrolls, which is a costly operation.

Intersection Observer API

That’s where the Intersection Observer API comes to the rescue:

const observer = new IntersectionObserver(changes => {
  for (const change of changes) {
    console.log(change.time);              // Timestamp when the change occurred
    console.log(change.rootBounds);        // Unclipped area of root
    console.log(change.boundingClientRect); // target.boundingClientRect()
    console.log(change.intersectionRect);   // boundingClientRect, clipped and intersected
    console.log(change.intersectionRatio);  // Ratio of intersectionRect to boundingClientRect
    console.log(change.target);             // The Element target
  }
}, {});

// Watch for intersection
observer.observe(target);

// Stop watching
observer.unobserve(target);

// Stop observing
observer.disconnect();

Example

Say, if we were to observe the element #catBox for visibility:

let options = {
  root: document.querySelector('#catBox'),
  rootMargin: '0px',
  threshold: 1.0
}

let observer = new IntersectionObserver(callback, options);
